Insulated Swinging Doors

Paylon offers low cost high quality Insulated Swinging Doors. These double or single doors are easy to install, maintain and are built to endure the abuse of medium to high traffic.

COMPARISON CHART
 Use this chart to pick the door that’s right for you!
Model Type of Traffic Applications Size Max Size Window Facing Frame $$Price
PC-1000 Heavy forklift Freezer, Cooler, Mfg. 1.75 10′x10′ 9×14 ABS Metal Premium
PE-9000 Heavy forklift Freezer, Cooler, Mfg. 1.88 10′x10′ 14×16 ABS Metal Premium
PE-8000 Med. forklift Cooler, Mfg., Storage 1.50 8′x8′ 14×16 ABS Metal Economical
PE-1500 Med. forklift Cooler, Mfg., Storage 1.50 8′x8′ 18×18 ABS Formed Economical
PE-10ALC Heavy-Foot, Cart Freezer, Cooler, Mfg. 3.50 10′x10′ 18×18 ALC/SS PVC Special App
PE-30ABS Heavy-Foot, Cart Freezer, Cooler, Mfg. 3.50 6′x8′ 18×18 ABS PVC Special App
PC-620ALCG Heavy-Foot, Cart Cooler, Mfg., Storage 1.00 8′x8′ 9×14 ALC/SS Comp Special App
All Doors are USDA approved and "Made in the USA"



Insulated Swinging Door – PC-1000


Impact plates and door jamb are optional
OverviewThis premiem built double swinging door has a heavy duty welded aluminum frame and a .125″ ABS sides making it ideal for heavy fork truck traffic.

Specifications

  • Heavy cart to heavy motorized traffic
  • Freezer/cooler/manufacturing
  • Available in stainless steel
  • Heavy duty hinges
  • sizes up to 10′ wide
test

Insulated Swinging Doors – PE- 9000


Teardrop bumpers and door jamb are optional
OverviewThis heavy duty double swinging door features a rugged reinforced inner steel frame and V-cam hinges. Built to take heavy forktruck use.

Specifications

  • Heavy cart to heavy motorized traffic
  • Freezer/cooler/manufacturing
  • Heavy Duty hinges
  • Sizes up to 10′ wide
  • Several options
test

Insulated Swinging Doors – PE- 8000


Bumpers, jamb and jamb guards are optional
OverviewThese rugged built double swinging doors fit several medium duty applications where light motorized equipment is used.

Specifications

  • Heavy cart to light motorized traffic
  • Cooler/warehouse/storage
  • Heavy Duty hinges
  • Sizes up to 10′ wide
  • Several options
test

Insulated Swinging Doors – PE-1500

Teardrop bumpers and door jamb are optional
Overview

This durable double swinging door features a seamless one-piece rotary molded body. Works great where wash-down applications are needed.

Specifications

  • Heavy cart to medium motorized traffic
  • Cooler/warehouse/storage
  • Standard size only
  • Several options
test

Insulated Swinging Doors – PE-10ALC


Door jambs are optional
OverviewThis special door features a PVC I-beam structural frame and a 3.5″ foam core giving it a R-factor of 25 48″ High Impact plates are standard equipment.

Specifications

  • Heavy foot to medium cart traffic
  • Freezer/cooler/manufacturing
  • Gas filled triple pane window
  • Heavy duty hinges
  • 8" high S.S. impact plates
  • Several options
test

Insulated Swinging Doors – PE-30ABS


Teardrop bumpers and door jamb are options
OverviewThis special door features a PVC I-beam structural frame and a 3.5″ foam core giving it a R-factor of 25 ABS side panles are scratch and dent resistant.

Specifications

  • Heavy foot to medium cart traffic
  • Freezer/cooler/manufacturing
  • Double pane window
  • Several options
test

Insulated Swinging Door PC-620ALCG


V-cam hinge, jamb and jamb guards are optional
OverviewThese double swinging doors are for applications requiring high sterilization, or to minimize product and dust accumulation.

Specifications

  • Heavy foot to medium cart traffic
  • Cooler/warehouse/storage
  • Full stainless steel available
  • Sizes up to 8′ Wide
  • Several options
